GE IS200JPDSG1AEC Mark VI Turbine Power Distribution Board
| Miejsce pochodzenia | NAS |
|---|---|
| Nazwa handlowa | GE |
| Numer modelu | IS200JPDSG1AEC |
| Minimalne zamówienie | 1PC |
| Cena | $6000 |
| Szczegóły pakowania | Nowa i oryginalna fabryka, indywidualne pakowanie pudełek |
| Czas dostawy | 5-7 dni |
| Zasady płatności | T/t |
| Możliwość Supply | 999pcs |
Skontaktuj się ze mną, aby otrzymać bezpłatne próbki i kupony.
WhatsApp:0086 18588475571
Wechat: 0086 18588475571
Skype'a: sales10@aixton.com
W razie jakichkolwiek wątpliwości zapewniamy całodobową pomoc online.
xSzczegóły Produktu
| Nazwa | GE IS200JPDSG1AEC Power Distributy Board | Identyfikator produktu | IS200JPDSG1AEC |
|---|---|---|---|
| Szereg | Mark VI | Funkcjonować | Turbina Awaryjna Trip Terminal Board |
| Głębokość/długość netto produktu | 330 mm | Wysokość netto produktu | 200 mm |
| Szerokość sieci produktu | 100 mm | Waga netto produktu | 2 kg |
| Gwarancja | 1 Year | ||
| Podkreślić | GE Mark VI turbine power board,turbine control distribution board,GE power distribution board with warranty |
||
opis produktu
GE IS200JPDSG1AEC Power Distribution Board
Product Specifications
| Attribute | Value |
|---|---|
| Name | GE IS200JPDSG1AEC Power Distribution Board |
| Product ID | IS200JPDSG1AEC |
| Series | Mark VI |
| Function | Turbine Emergency Trip Terminal Board |
| Dimensions (L×H×W) | 330mm × 200mm × 100mm |
| Weight | 2kg |
| Warranty | 1 year |
Product Overview
The GE IS200JPDSG1AEC is a Jumper Power Distribution Board (PCB) designed for the Mark VI Turbine Control System Series, extending compatibility to gas, steam, and wind turbines—an upgrade from the Mark V Series.
Key Features
- Power Distribution: Handles 28V DC input with multiple output configurations (6×6-pin, 3×2-pin, and 3×2-pin) and a 5-screw terminal (35A) for daisy-chaining
- Diagnostic Integration: Connects to PPDA I/O packs via 62-pin D-Shell and 50-pin ribbon cables for comprehensive system monitoring
- Enhanced Reliability: Includes overcurrent protection and isolated test rings for safe voltage measurements
- Compact Design: Sheet metal-mounted with detailed wiring diagrams for secure installation
- Compatibility: Works with JPDB/JPDF/JPDE boards and PPDA packs in Mark VIe's PDM system
Technical Details
As a critical 28V DC power management component, the IS200JPDSG1AEC receives power from external AC/DC or DC/DC converters, distributing it to control system components. Its design includes enhanced features over the JPDM module, such as additional fuses, output connectors, and support for PPDA I/O packs via ribbon cables, facilitating diagnostic integration.
Manufactured with A/E/C-rated revisions, it mounts on a sheet metal structure and integrates seamlessly into Power Distribution Module (PDM) systems while complying with safety standards through proper grounding via sheet metal brackets to Functional Earth (FE).
Compatible Components
| DS200DTBBG1ABB | DS200TCCAF1BDF |
| DS200SDCIG2AFB | IS200ISBBG1AAB |
| DS200SDCIG2AHB | IS200CABPG1BAA |
| DS200BDAAG1AAA | IS200DSFCG1AEB |
| DS200SIOBH1ABA | IS200DRLYH1BBB |
